DAICHI
The innovative machine that allows an integral branch of the tube

Araki proudly introduces this general-purpose burring machine that has aggregated our forty-year plastic forming know-how.(since its founding)

Burring, a technique that was once limited to skilled workers, can now be executed by many regular users.

Applying data from various types of standards, pipe thicknesses, materials to form each (forming) metal mold technique, we have made it possible to form advanced work pieces easily.

管の一体分岐を可能にする革新的マシン「TSUBASA」

Molding completed by simple operation, short time
Assembly operation
  • I put a pipe in wing lifter
  • Move the lifter lever operation, to adjust the position
  • Sets the inner mold, molded by operating the lever molded
The technology that enable design at a higher degree of freedom
Molding technique out of the same diameter as the main pipe

Moldable to the same size as the diameter of the main pipe from 1 inch minimum.
Tube fabrication technique of the same diameter as the mother ship is the only technology of only Company.

The molded a number of direction in the proximal part

Processing branch of the proximal part was difficult to easy.
Cross-and three-way, can be molded into many direction.

TSUBASA SPEC
Size (standard type)
Model The main body Right wing lifter Left wing lifter
Width High Depth Width High Depth Width High Depth
TSUBASA-200 1000mm
39.37㎡ 		2300mm
90.55in 		1200mm
47.24in 		2700mm
106.26in 		1100 ～ 1400mm
43.30 ～ 55.11in 		1000mm
39.37in 		6400mm
251.96in 		2300mm
90.55in 		1000mm
39.37in
TSUBASA-300 1200mm
47.24㎡ 		6600mm
259.84㎡
Molding is
Model Pipe outer diameter Materials
TSUBASA-200 25A ～ 200A
1in ～ 12in 		SUS304(L)TPA(S),SUS316(L)TPA(S),STPG,SGP
25SU～300SU SUS304(L)TPD,SUS316(L)TPD
TSUBASA-300 25A ～ 200A
1in ～ 12in 		SUS304(L)TPA(S),SUS316(L)TPA(S),STPG,SGP
25SU～300SU SUS304(L)TPD,SUS316(L)TPD
Three major benefits of safe, secure, inexpensive born by TSUBASA introduction
Significant cost reduction

A skilled worker takes time and, with a very high-priced welding coupling, welds it conventionally.

The molded directly branch branch pipe to pipe, significantly reducing the total cost
Improvement of quality

A defect is easy to appear conventionally to weld cylindrical complicated curve parts.

Welding improves reliability butt defect is less likely to occur, quality control mitigation
Strength up

It is thinning in the erosion and corrosion due to high temperature and high pressure.

Bifurcation reduced pressure loss shop stress concentration for a smooth shape
